Consew Model 205RB-1

205RB-1
Consew Model 205RB-1

Overview

Reverse Feed, Large Horizontal Axis Rotary Hook and Bobbin, Semi-Automatic Lubrication with Oil Pump, Single Needle, Drop Feed, Alternation Pressure Feet Lockstick Machine

See a Video demo of the 205RB-1 (click link): https://youtu.be/tPp4HSaj6PQ

Applications

  • For sewing medium to medium-heavy weight materials such as cloth, synthetics, vinyl, canvas, leather and various coated and laminated materials
  • Suitable for stitching operations on such products as leather coats, jackets, gloves, belts, wallets, handbags, briefcases and other travelware accessories, canvas products, auto and boat covers and tops, upholstery

Features

  • Independently adjustable upper and lower feeding mechanism
  • Horizontal axis, gear driven rotary hook
  • Large bobbin
  • Bobbin can be changed without removing object being sewn
  • Positive walking feet
  • Top and bottom feed mechanism insures even feeding of material
  • Reverse stitching
  • Maximum stitch length 3.2 s.p.i. (8mm)

ADDITIONAL INFORMATION

Specifications

Number of Needles 1 (Single)
Feeding Mechanism Walking Foot
Workspace Standard Workspace
Standard or Full Function Standard Functions
Speed, Max (S.P.M.) 2000
Clearance Under Presser Foot Hand 1/4" (6.5mm) Foot 5/8" (16mm)
Stitch Length 3.2 s.p.i. (8mm)
Hook Size 24312/24310
Work Space 10 5/16" (262mm)
Needle Metal 135 x 17
Bobbin Pre-Wound 24311
Stitch Type 301
Weight 164 lbs
Needle Bar Stroke 1 29/64" (37mm)
Work Surface 7" x 18 23/32" (178mm x 475mm)
