Consew Model 328RB-2

328RB-2

Overview

High Speed, Two Needle, Angular Stitching (Split Needle Bar), Drop Feed, Needle Feed, Walking Foot, Lockstitch Machine

With: Compound Feed and Walking Foot, Centra-Lube Semi-Automatic Lubrication System, Large Vertical Axis Hooks and Bobbins, Disengageable Right and Left Needle Bars, Reverse Feed, Safety Clutch

Also available 327RB-2 (needle feed)

Applications

  • For medium to heavy-duty materials such as leather, canvas, vinyls and various laminated and coated materials
  • Designed for sewing operations which require decorative or functional angular stitching such as collars, lapels, pockets, pocket flaps, etc.
  • Used for stitching such products as men's, ladies' and childrens' coats, ski wear, jeans, handbags and travelware accessories
  • General parallel / two-needle stitching.  Top stitching with split bar for angular sewing turns

Features

  • Compound feed, walking foot mechanism assures perfect feeding of sewing material
  • Large hooks and bobbin cases with their own thread take-up mechanism assure uniform and perfect stitching with minimal bobbin changes
  • Easy operation of disengageable right and left needle bars by use of finger-touch lever
  • Centra-Lube® semi-automatic lubrication system
  • Automatic hook lubrication
  • Oil fed take-up
  • Stitches per minute - 2200 *
  • Reverse stitching
  • Various gauge sets available
  • Safety clutch protects the hooks from being damaged
  • Simple adjustment permits raising and lowering the center foot which allows for sewing different thicknesses of material

INFORMATION
328RB-2 PDF Spec sheet

Specifications

Number of Needles 2 (Double)
Feeding Mechanism Walking Foot
Workspace Standard Workspace
Standard or Full Function Standard Functions
Speed, Max (S.P.M.) 2200
Clearance Under Presser Foot 11/32" (8.5mm)
Stitch Length 4 s.p.i. (6.5mm)
Work Space 10" (258mm)
Needle 135 x 17
Bobbin Metal 10408 Pre-Wound U
Bed Size 7" x 20 3/8" (177mm x 518mm)
Stitch Type 301
Needle Bar Stroke 1 1/4" (32mm)
Hook 16407
Needle Distances 1/8" (3.2mm)-1"(25.4mm) (1/4") is standard
