Consew Model P1510RBL-25-7DD/220

P1510RBL-25-7DD/220

Overview

High Speed, Direct Drive, Single Needle, Walking Foot,
Lockstitch Machine. Comes in 14" 18" and 25" workspace
(see catalog sheet.)  This is the 25" Long Arm version.
Comes with full auto functions (-7DD has automatic thread trim)
(also available is -DD without automatic thread trim)

Currently Available in 220VAC Version ONLY.



applications

  • Designed for automotive, marine, leather, canvas and general upholstery.
  • For sewing light to heavy-weight fabric, canvas, leather, vinyl, synthetics and various laminated and coated materials
  • Designed for stitching such products as auto, boat and furniture upholstery, tarpaulins, covers, awnings, tents, umbrellas, handbags, luggage, travelware accessories, sports and camping equipment, wearing apparel, outdoor clothing, footwear, foundation garments, orthopedic appliances, etc


Features - (7DD)

  • Large Top Load Bobbin
  • 25" Long Arm
  • Built-in Bobbin Winder
  • Walking Foot
  • Climbing Device
  • Roll-In, tucks the top thread under fabric when it starts!
  • Automatic Foot Lift
  • Automatic Reverse
  • Semi-Automatic Lubrication
  • Automatic Thread Trim (on -7DD only)
  • Servo motor connected direct to top shaft

List of Models  (aLL OPERATE AT 220VAC AT THIS TIME)

  • Full Automatic Function Machines WITH Auto Thread Trim (-7DD)
    P1510RB-14-7DD/220  14” workspace  (355 mm)
    P1510RBL-18-7DD/220  18” workspace (457 mm)
    P1510RBL-25-7DD/220  25” workspace (635 mm)
  • Automatic Function Machines WITHOUT Auto Thread Trim (-DD)
    P1510RB-14-DD/220  14” workspace (355 mm)
    P1510RBL-18-DD/220  18” workspace (457 mm)
    P1510RBL-25-DD/220  25” workspace (635 mm)

Additional information

SPECIFICATIONS

  • Speed, maximum: 2000 - 2500 spm   (* Speed depends on thread, material and operation.)
    Clearance Under Foot 9/16" (14mm)
    Needle: 135 x 17 (DPX17)
    Stitch Length; Max. 9mm Adjustment By Dial
    Presser Foot Lift By Hand: 9 mm /  By Knee: 16mm
    Lubrication: Semi-Automatic
    Bobbin:  U or S
    Power: 220 VAC

Specifications

Number of Needles 1 needle
Workspace Long Arm
Standard or Full Function Computerized Functions
Speed, Max (S.P.M.) 2000 - 2500 spm
Motor Type Direct Drive Internal
Clearance Under Presser Foot Hand 9mm , Knee 16mm
Stitch Length 9mm Max.
Work Space 25"
Needle 135 x 17 (DPX17)
Weight 279 lbs (127 kg)
Electric 220 vac
