Consew Model 7360RH-R

7360RH-R
Consew Model 7360RH-R

Overview

Ultra High Speed, Single Needle, Drop Feed, Lockstitch Machine
The 7360RH is the heavy duty version, The 7360RH-R comes with a Roller Presser  Foot (not shown here.)

With: Automatic Lubrication, Reverse Feed, Japanese Components

Applications

  • For sewing light to heavy-weight materials including cottons, knits, polyester, nylon, sheer fabrics and denim
  • Suitable for stitching such products as blouses, shirts, men's, ladies and children's apparel, uniforms, overalls, lingerie, etc.
  • Heavyweight fabrics such as jeans can be sewn by changing the needle plate, feed dog, foot, stitch regulator, hook and needle bar

Features

Specifications

Number of Needles 1 (Single)
Feeding Mechanism Drop Feed
Workspace Standard Workspace
Standard or Full Function Standard Functions
Speed, Max (S.P.M.) 3000 , 3500
Clearance Under Presser Foot 1/4" (6mm) , 1/4" (6mm)
Stitch Length 3 1/2 s.p.i. (7mm) , 5 s.p.i. (5mm)
Work Space 10" (258mm) , 10" (258mm)
Needle 135 x 5 , 16 x 257
Bobbin Metal 22T4-017
Pre-wound L , Metal 78T4-005
Pre-wound M
Bed Size 7" x 18 7/8" (177mm x 477mm) , 7" x 18 7/8" (177mm x 477mm)
Stitch Type 301 , 301
Needle Bar Stroke 1 1/4" (31.8mm) , 1 5/16" (33mm)
Hook 22T4-011D , 48T4-001A
