Consew 277RFS-3

Consew 277RFS-3

Consew 277RFS-3

Consew 277RFS-3

Consew 277RFS-3

Consew 277RFS-3

Consew 277RFS-3

SKU: 277RFS-3

Overview

Heavy Duty, Narrow Cylinder Arm, Single Needle, Drop Feed, Needle Feed, (Compound Feed,) Alternating Presser Feet, Lockstitch Machine.

with Centra-lube® Semi-automatic Lubrication System, Horizontal Axis Rotary Hook, Reverse Feed.

Model 277RFS-3 is equipped for feed synchronized binder with horizontal feed and has a cylinder bed diameter of 1-13/16" (46mm) diameter

Product Resources

Download Manual Download Parts Book Download Catalog Page

Applications

For sewing light to heavy-weight fabrics, leather, vinyl, upholstery, synthetics, canvas, and various coated and laminated materials
Especially designed for products with narrow openings
For stitching tubular and curved work
Suitable for sewing products such as hats, caps, shoes, sandals, slippers, tarpaulins, covers, sails, tents, awnings, umbrellas, bags, luggage, handbags, travelware accessories, wearing apparel, etc.
Models 277RFS-3 & 277RBFS are designed for Tape Binding

Features

Narrow cylinder arm: 46 mm diameter (Model 277RFS-3)

Horizontal axis rotary hook

Large bobbin available (Model 277RBFS-3)

Compound feed, walking foot mechanism ensures even feeding of several plies or slippery material

Simple adjustment allows raising and lowering of the center foot to accommodate different material thicknesses

Specifications

Number of Needles: 1 (Single)

Feeding Mechanism: Walking Foot

Workspace: Standard Workspace

Standard or Full Function: Standard Functions

Speed, Max (S.P.M.): 2300

Stitch Length: 4.2 s.p.i. (15/64" or 6mm)

Work Space: 10 5/32" x 4 11/32" (258 x 110mm)

Needle: 135 x 17

Bobbin: 17035 L

Weight: 179 lbs (81kg)

Needle Bar Stroke: 1 5/16" (33.2mm)

Cylinder Diameter: 1-13/16" Dia. (46mm)
