Consew CN897VCB-7DD

Name: Consew CN897VCB-7DD
Brand: Consew
SKU: CN897VCB-7DD
Availability: InStock

SKU: CN897VCB-7DD

Overview

The CN897VCB-7DD is a cylinder-bed model specifically tailored for binding in circular or curved garment areas. It combines the versatility of the CN-897VC’s structure with the binding-specific functionality needed in modern apparel production.

Product Resources

Download Catalog Page

Applications

Binding operations on tubular garments
Curved hem and cuff binding
Tape attaching in circular areas
General seaming and elastic insertion

Features

Cylinder-bed optimized for binding
Fully automatic lubrication with filter
Thread and needle cooling
Differential feed with micrometric adjustment
High-speed operation up to 6,000 S.P.M.
UY128GAS needle compatibility

Specifications

Max Sewing Speed: 6,000 S.P.M.
Lift of Presser Foot: 7.0 mm
Differential Ratio: 1:0.3 ~ 1:2.9
Standard Needle Gauge: 3-needle, 5.6 mm
Optional Needle Gauges:
2 needles: 3.2, 4.0, 4.8, 5.6, 6.4 mm
3 needles: 5.6, 6.4 mm
Stitch Length: 1.4 ~ 3.6 mm
Needle Bar Stroke: 31 mm
Needle System: UY128GAS

Configurations

2 needles / 2 loopers / 4 threads
3 needles / 2 loopers / 5 threads
