Consew CN897VF-7DD

Name: Consew CN897VF-7DD
Brand: Consew
SKU: CN897VF-7DD
Availability: InStock

SKU: CN897VF-7DD

Overview

The CN897VF-7DD is a high-speed flat-bed coverstitch machine equipped with a direct drive motor and advanced automation. Designed for efficiency and precision in operations such as hemming, seaming, and elastic inserting, it supports 2-needle/4-thread and 3-needle/5-thread configurations. Its micrometric differential feed, automatic lubrication, and electronic thread control make it ideal for modern sewing environments.

Product Resources

Download Manual Download Parts Book Download Catalog Page

Applications

Flat seaming on knitwear and woven garments
Bottom hemming
Tape binding
Elastic insertion
Activewear and underwear production

Features

Flat-bed design with direct drive motor
Electronic push-button stitch regulator
Fully automatic lubrication with visual flow indication
Replaceable oil filter with external cooling
Differential feed with micrometric adjustment (1:0.7 ~ 1:2.0)
Needle cooling and thread lubrication system (silicone-based)
Compatible with UY128GAS needles
Programmable thread trimming (optional electric or pneumatic)
Tape cutter and thread wiper options available
Low-noise, high-efficiency operation

Specifications

Number of Needles: 2, 3
Feeding Mechanism: Differential
Speed, Max (S.P.M.): 6000
Max Stitch Length: 1.4 ~ 3.6mm
Presser Foot Lift: 7.0mm
Needle Bar Stroke: 31mm
Needle Used: UY128GAS
Looper: 2
Standard Distance Between Needles: 5.6mm (3-needle)
Differential Ratio: 1 : 0.3 ~ 1 : 2.9
Weight: 183 lbs
Optional Needle Gauges: 2 Needles - 3.2, 4.0, 4.8, 5.6, 6.4 mm, 3 Needles - 5.6, 6.4 mm

Configurations

2 needles / 2 loopers / 4 threads
3 needles / 2 loopers / 5 threads
