Consew CN897VFB-7DD

Consew CN897VFB-7DD

SKU: CN897VFB-7DD

Overview

The CN897VFB-7DD is a flat-bed coverstitch machine with direct drive, specifically configured for binding applications. With its high-speed performance, advanced lubrication system, and optional automation attachments, it ensures consistent results across a range of light to heavy-weight fabrics.

Product Resources

Download Catalog Page

Applications

Binding on flat garments
Bottom hemming
Elastic insertion
Coverstitching for uniform and performance clothing

Features

Flat-bed design with built-in direct drive motor
Electronic stitch length control
Push-button thread regulator
Fully automated lubrication and oil cooling system
Micrometric differential feed (1:0.7 ~ 1:2.0)
Thread and needle cooling using silicone
Available options for thread trimming and tape cutting
Quiet operation for continuous use
Standard UY128GAS needle compatibility

Specifications

Max Sewing Speed: 6,000 S.P.M.
Lift of Presser Foot: 7.0 mm
Differential Ratio: 1:0.7 ~ 1:2.0
Stitch Length: 1.4 ~ 3.6 mm
Needle Bar Stroke: 31 mm
Standard Needle Gauge (3 needles): 5.6 mm
Optional Gauges:
2 needles: 3.2, 4.0, 4.8, 5.6, 6.4 mm
3 needles: 5.6, 6.4 mm
Needle System: UY128GAS

Configurations

2 needles / 2 loopers / 4 threads
3 needles / 2 loopers / 5 threads
