Consew CN897VFB-1

Name: Consew CN897VFB-1
Brand: Consew
SKU: CN897VFB-1
Availability: InStock

SKU: CN897VFB-1

Overview

The CN897VFB-1 is a flat-bed version of the high-speed coverstitch machine, optimized for binding applications. It supports both 2-needle and 3-needle configurations and is built to handle light to heavy materials with consistency and ease.

Product Resources

Download Catalog Page

Applications

Binding operations on flat garments
Bottom hemming
Elastic attaching
General coverstitch seaming

Features

Flat-bed binding configuration
Micrometric differential feed
Automatic lubrication with visible flow control
External oil cooling system
Thread and needle lubrication
Compatible with standard UY128GAS needles

Specifications

Max Sewing Speed: 6,000 S.P.M.
Lift of Presser Foot: 7.0 mm
Differential Ratio: 1:0.7 ~ 1:2.0
Standard Needle Gauge: 3-needle, 5.6 mm
Optional Needle Gauges:
2 needles: 3.2, 4.0, 4.8, 5.6, 6.4 mm
3 needles: 5.6, 6.4 mm
Stitch Length: 1.4 ~ 3.6 mm
Needle Bar Stroke: 31 mm
Needle System: UY128GAS

Configurations

2 needles / 2 loopers / 4 threads
3 needles / 2 loopers / 5 threads
